65-108Mhz(only for FM)

VHF:136-174Mhz(Rx/Tx) UHF:400-520(Rx/Tx)

Memory channels

Up to 128 channels

Frequency stability

2.5ppm

Frequency step

2.5kHz/5kHz/6.25kHz/10kHz/12.5kHz/25kHz

Antenna impedance

50Ω

Operating temperature

-20°C to +60°C

Supply voltage

Rechargeable Lithium-Ion mAh7.4V/1800

Consumption in standby

≤75mA

Consumption in reception

380mA

Consumption in transmission

≤1.4A

Mode of operation

Simplex or semi-duplex

Duty cycle

03/03/54 min.(Rx/Tx/Standby)

Dimensions

58mm*110mm*32mm

Weight

130g(approximate)

TRANSMITTER

RF power

4W/1W

Type of modulation

FM

Emission class

16K&F3E/11K&F3E(W/N)

Maximum deviation

≤±5kHz/≤±2.5kHz(W/N)

Spurious emissions

<-60dB

RECEIVER

Receiver sensitivity

0.2μV(at 12dB SINAD)

Intermodulation

60dB

Audio output

1000mW

Adjacent channel selectivity

65/60dB
